Buffer-JRB

A supplementary range of cylindrical mountings fora wide range of applications. They can be loaded either incompression or shear taking into considerationindividual demands for actual applications. Rubber material: natural rubber, blackThere are three hardness options available: 45.60,and 75,corresponding to the suffxes -A,-B.and -C respectively.

Inquiry

Download

Product Description

"Metalwork : mild steel, plated. Natural rubber, bonded, cylindrically shaped. Fixing by screws, nuts or mixed. European thread standards are not always consistent with French thread standards so Paulstra has created the Radiaflex® Europe range based on those standards. The end stop version is now available with a threaded hole in addition to the threaded stud.

DESCRIPTION

Metalwork : mild steel, plated.

Natural rubber, bonded, cylindrically shaped.

Fixing by screws, nuts or mixed.

European thread standards are not always consistent with French thread standards so Paulstra has

The end stop version is now available with a threaded hole in addition to the threaded stud.

CHARACTERISTICS

The design of the RADIAFLEX® mount gives the following basic characteristics:

the rubber works in :

- compression (axial),

- shear (radial),

- compression/shear according to the fixing method.

Specifications

Model	Diameter	Height	Bolt	Bolt	Average stiffness Vertical Kg/mm			Maximum compression ratio
	D	H	G	L	45ShA	60 ShA	75	mm
							ShA	mm
JRB0808M306A	8	8	M3	6	3.8	7.2	11.3	1.6
JRB0808M306A	8	8	M3	6	3.8	7.2	11.3	1.6
JRB0808M306A	8	8	M3	6	3.8	7.2	11.3	1.6
JRB0808M306A	8	8	M3	6	3.8	7.2	11.3	1.6
JRB0808M306A	8	8	M3	6	3.8	7.2	11.3	1.6
JRB0808M306A	8	8	M3	6	3.8	7.2	11.3	1.6

Drawing

This is a bush made up of 2 concentric tubes between which of elastomer is bonded. Under the effect of external forces or torques, the relative movement of the tubes will cause an elastic deformation of the elastomer. By consulting the service conditions, a bush should be chosen which will remain within its elastic operational limits..

JCB44 MOUNT
JCB44 MOUNT

DESCRIPTION

CHARACTERISTICS
